With a unique design that eliminates preventative maintenance schedules,
get the most of your stationary inventory without having to worry about extra patients visits and replacement filter costs.
Design changes in November 2013 drastically increased overall durability, and improved the reliability of valves and sieve beds. This has reduced failure rates and has set a new standard for high-performing 5 LPM concentrators.
Combining low failure rates with no preventative maintenance schedule creates a high-performing stationary with a low total cost of ownership.
LIGHTWEIGHT AND POWER-EFFICIENT
At only 30 lbs (13.6 kg) with side and top handles, the VisionAireTM 5 is lightweight and easy to deliver.
Its 290 W power draw at all settings is incredibly efficient.
Product Features
- Maintenance-free design
- Lightweight and easy transport
- Well-defined audible alarm system for easy diagnosis
- Lockable flow meter
- Dual-function hour meter
SPECIFICATIONS
FLOW RATE : 1.0 - 5.0 LPM
DIMENSIONS : 20.8 x 14.1 x 11.5 in (52.8 x 35.8 x 29.2 cm)
WEIGHT : 30 lbs (13.6 kg)
SOUND LEVEL : 39.53 dB(A) ± 0.41 dB(A) @ 3
02 CONCENTRATION : 90 % (+5.5 / -3 %)
POWER CONSUMPTION : 290 W (All Flow Rates)
ALARMS : Power Failure, High Pressure, Low Pressure, No Flow, Low O2 Concentration (Optional)
MAXIMUM TUBING : 50 ft (15.2 m)
REQUIRED PREVENTATIVE MAINTENANCE SCHEDULE : None
